Nujira unveils plans to open US design center

Nujira Ltd, the world’s leader in Envelope Tracking (ET) technology, has today announced plans to open a new design center in the US in March 2014. The California design center is Nujira’s first expansion outside of the UK, and comes as ET technology continues to gain momentum in 4G smartphones.

Tim Haynes, CEO, Nujira, said: “We have a track record of world firsts in Envelope Tracking, and our ET ICs offer the highest performance available in the market today. Nujira’s solution is gaining considerable traction worldwide, enabling the expansion of our global team to support our technology roadmap and also tap into new pools of resource to build on our world-class design team in the UK.”

Haynes added: “The RF front end of LTE smartphones is a huge growth area, and offers one of the most stimulating and exciting design challenges in IC design today. Getting the best performance results with ET requires creative and highly skilled analog, RF and switch-mode IC designers. We’re looking for top-tier engineers who think they have what it takes to join our team.”

Taking advantage of the deep pool of IC design expertise on the West Coast of the US, Nujira’s new design center will focus on the development of next generation ET ICs. It will also provide a base for local applications and operations support to US-based customers and partners.

Nujira is currently looking at several locations in Silicon Valley for the new design center, which will open in March 2014. Interested candidates should submit resumes to jobs@nujira.com
